CNC Control Knife Pleating Machine 1050mm Width 220V / 380V 50Hz

Name: CNC Control Knife Pleating Machine 1050mm Width 220V 380V 50Hz
Brand: MOER
Price: 1 USD

Brand Name : MOER

Model Number : JSMRK6-1050-II

Certification : CE

Place of Origin : China

MOQ : 1

Price : negotiate

Payment Terms : L/C,T/T

Delivery Time : 30-45days

Packaging Details : plywood cases

Machine Width : 1050mm

Control System : PLC

Pleating Height Range : 3-70mm

Production Capacity : 1000 pieces/hour

Filter Type : Air Filter

Voltage : 220V/380V

Filter Efficiency : 99.97%

Power Source : Electric

Material : Metal Steel

Warranty : 1 year

Frequency : 50Hz

Contact Now

1050mm Width Servo Motors Controlled CNC Knife Pleating Machine

(Suitable materials for pleating like: wooden paper, non-woven, P.P synthetic media, glass fiber, active carbon, mesh, and multi-layers pleating.)

Technical Parameters:

Max width	1050mm
adjustable pleating height	10-100mm((Pleat depth can be changed automatically by CNC control)
Pleating speed	0-400pleats/min
Power supply	380V/220V/50hz
Motor power	3kw
Pre-heating power	10KW
Heating temp	normal-300℃
Working air pressure	0.6Mpa
M/C weight	850kg
M/C size	slitting 1400x1600x1400 (LWH)
4pcs customized brand servo motors

Features
1. The folding machine adopts upper and lower knife alternatively perform folding, from the knife automatic adjustment by computer, can reach different fold higher requirements, accurate size.
2. In the paper folding machine automatic dotting counter, folding processing and preheating and forming etc.
3. This machine can also be folded all the different rules of fold change.
4. Folding knife of this machine can change any angle, ensure the folding does not damage any kind of filter material.

Applications
This production line is suitable for the automobile industry three, hydraulic industry, purification industry, the water treatment industry.
